90 GPM Circulator Pump
90 GPM Circulator Pump
PDIPN:
109771
Key Features
Regular price
$1,316.00
Sale price
$1,316.00
Regular price
Overview
Overview
SPECIAL ORDER ITEM. Review Returns Policy before purchase. Cartridge Cirulation Pumps are designed for efficient water circulation in residential and light commercial hydronic heating and hot water systems. Featuring a unique, replaceable cartridge that contains all moving parts, they allow for easy maintenance without replacing the entire pump. Their compact, direct-drive design ensures quiet operation and low energy consumption while delivering reliable, long-lasting performance.
Specifications
Specifications
Dimensions and Measurements
- Drain Connection Size (in) 1-1/2 in
- Water Connection Size (in) 1-1/2 in
Characteristics and Features
- Manufacturer Warranty Refer warranty as per manufacturer website
Number Of
- Number of Speeds 1
Material
- Material Stainless Steel
Yes/No Features
- Valve Included (Yes/No) No
Performance Capacity
- Speed Rating (rpm) 3450 rpm
- Flow Rate (gpm) 90 gpm
- Head Range (ft) 46 ft
- Horsepower (HP) 1/6 hp
- Temperature Rating (deg) 225 deg F
Electrical Information
- Frequency Rating (Hz) 60 Hz
- Amperage (A) 1.9/1 A
- Voltage (V) 115V
Operation Detail
- Power Rating (W) 124.28 W
