1/2 in Pressure Reducing Valve
1/2 in Pressure Reducing Valve
PDIPN:
20177
Key Features
Regular price
$388.00
Sale price
$388.00
Regular price
Overview
Overview
SPECIAL ORDER ITEM. Review Returns Policy before purchase. This Pressure Reducing Valve is designed to handle sandy or debris-laden water systems while delivering high-flow capacity for residential, commercial, and new construction applications. It complies with universal plumbing code requirements for reliable system performance. The stainless steel strainer features a standard 20-mesh configuration with a separate-access cover for easy cleaning. A bronze threaded bell enhances corrosion resistance and provides quick access to internal components, helping reduce maintenance time. The balanced internal design of the 600XL ensures accurate downstream pressure regardless of inlet pressure variations.
Specifications
Specifications
Dimensions and Measurements
- Fitting Size (in) 1/2 in
- Inlet Diameter (in) 1/2 in
- Outlet Diameter (in) 1/2 in
- Thread Size (in) 5 in
- Valve Size (in) 1/2 in
- Pressure Rating (PSI) 300 PSI
- Temperature Rating (deg) 140 deg
Characteristics and Features
- Plumbing Connection Type NPT
Number Of
- Quantity (Count) 1
Material
- Material Bronze
