100 Series 110 GPM Circulator Pump
100 Series 110 GPM Circulator Pump
PDIPN:
64343
Key Features
Regular price
$1,830.00
Sale price
$1,830.00
Regular price
Overview
Overview
SPECIAL ORDER ITEM. Review Returns Policy before purchase. The Series 100 is a leader in applications such as hydronic heating and domestic hot water circulation, with over 10 million units installed. Series 100's three-piece, oil lubricated design provides for easy field service with bearings, shaft and seal all housed in an assembly which can be easily repaired or replaced. The Series 100 oil lubricated motor is specifically designed for the Series 100, and its resilient mounting provides quiet, dependable service with minimum annual lubrication. UL and CSA listings are standard. The design of this motor, coupled with its overall hydraulic performance, allows the Series 100 to overcome system related noise caused by valves, fittings, or piping.
Specifications
Specifications
Dimensions and Measurements
- Drain Connection Size (in) 2-1/2 in
- Water Connection Size (in) 2-1/2 in
Characteristics and Features
- Manufacturer Warranty Refer warranty as per manufacturer website
Number Of
- Number of Speeds 1
Material
- Material Cast Iron
Yes/No Features
- Valve Included (Yes/No) No
Performance Capacity
- Speed Rating (rpm) 1725 rpm
- Flow Rate (gpm) 110 gpm
- Head Range (ft) 16 ft
- Horsepower (HP) 1/4 hp
- Temperature Rating (deg) 225 deg F
Electrical Information
- Frequency Rating (Hz) 60 Hz
- Amperage (A) 0.125
- Voltage (V) 115V
Operation Detail
- Power Rating (W) 186.42 W
