1/4 Inch Lead Free Brass Ball Valve, Brass
JOMAR 100-101SSG 1/4 LF BRS BLVLV
PDIPN:
198782
Key Features
Regular price
$11.79
Sale price
$11.79
Regular price
Overview
Overview
SPECIAL ORDER ITEM. Review Returns Policy before purchase. Engineered for high-pressure plumbing systems, this 1/4 in boiler drain valve features a full port design to ensure maximum flow capacity. The unit is constructed from dezincification resistant brass alloy, providing structural integrity in demanding environments. Rated for pressures up to 600 psi and temperatures ranging from 0 to 400 degrees Fahrenheit, it handles extreme thermal and mechanical stress. The threaded connection allows for secure integration into existing piping, while the lever handle provides quick quarter-turn shut-off control. A blow-out proof stem and gland follower with a single O-ring design prevent leaks and enhance operational safety in residential or commercial water applications.
Specifications
Specifications
Dimensions and Measurements
- Thread Size (in) 1/4 in
- Water Connection Size (in) 1/4 in
- Pressure Rating (PSI) 600 PSI
- Temperature Rating (deg) 400 deg
Characteristics and Features
- Port Type Full Port
- Plumbing Connection Type NPT
- Valve Handle Type Lever
Number Of
- Quantity (Count) 1
Material
- Material Brass
