12 in 8 Gallon Pre Charged Verticle Expansion Tank for Water Heaters, Red
12 in 8 Gallon Pre Charged Verticle Expansion Tank for Water Heaters, Red
PDIPN:
45134
Key Features
Regular price
$5,546.00
Sale price
$5,546.00
Regular price
Overview
Overview
SPECIAL ORDER ITEM. Review Returns Policy before purchase. This potable water expansion tank is used on gas, oil, electric, indirect-fired, commercial water heater and hot water storage tank applications to absorb the increased volume of water created by thermal expansion. It also maintains balanced pressure throughout the water supply system by keeping system pressure below the T and P relief valve setting. This carbon steel tank with field-adjustable air charge is built with tank volume 8.0 gallons, pre-charged to 40 PSI, has fixed FDA-approved butyl rubber diaphragm, and 3/4 in stainless steel male NPT inlet connection and a 0.302-32 in charging valve connection (standard tire valve) to facilitate on-site charging of the tank to meet system requirements.
Specifications
Specifications
Dimensions and Measurements
- Diameter (in) 12 in
- Overall Height (in) 20 in
- Drain Connection Size (in) 3/4 in
- Water Connection Size (in) 3/4 in
Characteristics and Features
- Manufacturer Warranty Limited Lifetime Warranty
Material
- Material Fixed Butyl
Performance Capacity
- Capacity (gal) 8 gal
- Temperature Rating (deg) 240 deg F
