1/4 in Full Port Ball Valve, Chrome Plated
WATS 88005596 1/4 BRS LF BALL VLV
PDIPN:
139659
Key Features
Regular price
$33.75
Sale price
$33.75
Regular price
Overview
Overview
SPECIAL ORDER ITEM. Review Returns Policy before purchase. Engineered for commercial and industrial fluid control, this 2-piece full port ball valve manages a wide range of liquids and gases with reliable flow capacity. The valve features a forged copper silicon alloy body and adapter, ensuring compliance with lead-free requirements for potable water systems. Certified to NSF- and ANSI standards, the unit is built to withstand demanding environments with a pressure rating up to 600 psi and an operating temperature range spanning from freezing to high-heat conditions. A fluorocarbon elastomer stem O-ring is integrated to prevent leaks, while the lever handle provides quick quarter-turn shut-off control for FIP threaded connections.
Specifications
Specifications
Dimensions and Measurements
- Water Connection Size (in) 1/4 in
- Pressure Rating (PSI) 600 PSI
- Temperature Rating (deg) 400 deg
Characteristics and Features
- Port Type Full Port
- Plumbing Connection Type FIP
- Valve Handle Type Lever
Number Of
- Quantity (Count) 1
Material
- Material Brass
